Sagi IF101S - Inputs Outputs

58
3222180_GB
INPUTS OUTPUTS
1. Select MENU by rotating the knob
SOFT -18°C
HARD -18°C
IFR INFINITY
SOFT +3°C
HARD +3°C
MENU
2. Press the knob to enter section MENU
SOFT -18°C
HARD -18°C
IFR INFINITY
SOFT +3°C
HARD +3°C
MENU
3. Select SERVICE by rotating the knob
AUTOMATIC
MULTY
COOLING
STORED
SETTING
SERVICE
HACCP
FUNCTIONS
MENU
4. Press the knob to enter section
SERVICE
AUTOMATIC
MULTY
COOLING
STORED
SETTING
SERVICE
HACCP
FUNCTIONS
MENU
5. Select INPUTS OUTPUTS by rotating
the knob
MENU
SERVICE
RESTORE
MULTY
PARAMETERS
ALARMS
FIRMWARE
ALARMS RESET
INPUTS OUTPUTS
6. Press the knob to view the list INPUTS
OUTPUTS
MENU
SERVICERESTORE
MULTY
PARAMETERS
ALARMS
FIRMWARE
ALARMS RESET
INPUTS OUTPUTS
7. Select to exit from the view
MENU
SERVICE
IN/OUT
NEEDLE
UNDERSKIN
EXTERNAL
AIR
EVAPORATOR
CONDENSER
27°C
26°C
26°C
25°C
29°C
28°C
