SAIC D90 Series - Jump Start; Battery Disconnection

To Next Page

To Previous Page

EmergencyTroubleshooting

JumpStart

Batterydisconnection

Wearprotectiveglovesandgogglesduringthe

operationsrelatedtobattery.

Donotuseopenres,generatesparksorsmokein

thebatteryarea.Oryouwillbeinjuredandthevehicle

willbedamaged.

Todisconnectthebattery,besuretodisconnectthenegative

(-)groundingterminalrstandthenthepositive(+)one.When

connectingthebattery,pleaseinstallandtightenpositivecable

(+)rstandthennegative(-)cable.Andcovertheterminalswith

Vaseline.
