Preface

ManualIntroduction

Aboutthismanual

ThismanualappliestoD90seriesPassengercar.

Caution

Theinformationcoveredbythismanualdoesnotaimto

certainmodelandvariant,thussomecontentsinthismanual

maybeinapplicabletoyourmodel.

Thisvehicleproductfollowsenterprisestandard

Q31/0110000019C040.

Theguresinthemanualareschematics,foryourreference

only.

Promptinformation

Warning

Thissignmeansthatyoumustabidebyrelevant

stepsstrictlyandaccuratelyinordertoavoid

causingpersonalinjuriestoyourselfandother

persons.

Caution

Thissignmeansyoumustabidebyrelevantstepstoavoid

damagingyourvehicle.
