11
Chapter 3
33333
Connectors & controls
Connectors & controls 3
This chapter provides a description of all connectors on the Control Panel and
gives guidelines to cabling. It has the following sections:
• Connectors
• Cabling
• Controls
3.1 Connectors
The drawing below shows the connectors and the ground stud on the rear
panel of the Control Panel.
The connectors are described in detail in the following sections.
USB
Ground Stud
Auxiliary,
Speaker
and Alarm
Accessories,
Handset or
Speaker Microphone
Primary LAN
RJ 45
Secondary LAN
RJ 45
Power and
Remote on
12—24V DC
