Chapter 4: Verification
Check of the Control Panel 21
44444
Verification
You can test the following parts and functions:
• Touch - the touch screen
• Controls - power button and dim/volume knob
• Display - pixel and colour check
• Audio - test of microphone and loudspeaker
• USB - test of USB connection
• Light sensor
• Alarm output - test of connection to connected alarm systems
• NMEA
• LAN
Further details for each test are shown on the screen for the individual
test.
4. To run all tests, tap Run all tests, located in the upper right corner.
To run one of the tests, tap the test and follow the instructions on the
screen.
5. To leave the self test and go to a user application (if any are installed), tap
the icon shown in the screen below.
Tap to go to installed user application
