VHF 5000 System Functional unit workshop service
3-15
• Secure the 8-pin connector at front of the PSU to
the PSU cover using a small amount of sealing
compound (must not contain acid).
• Connect the two (2) 20-pin ribbon cable connectors
to the RF board and the Baseband board
respectively.
• Connect the front part (Control Unit) to the radio. Assemble the cover of the radio and perform a final test
of the complete radio.
1007
Fig. 22
Fig. 23
Fig. 24
