If a digital value is entered , and press “ SURE ” soft key to confirm. the screen return to the
first page of Initial Setup 2 menu. You can use the same method as described in setup 1 to
setup other parameters listed in the menu.
Load Cell Unit: K g
Scale Capacity: Min:1 Max:200000
Scale Division:
0.1 、 0.2 、 0.5 、 1 、 2 、 5 、 10 、 20 、 50 、 0.01
、
0.02 、 0.05 、 0.001 、 0.002 、 0.005
Scale Code: Min:0 Max:500
N ote: data setup is available in two kinds, value kind, and option kind, below menu
’
s
input
and selction operation can refer to intial setup 1 and intial setup 2, here do not describe in
details.
Press “ code data ” in “ initial setup2 ” menu to enter “ scale code ” menu the first page.
Description Min Max
P to L (Pivot to load cell D) 0 1000000mm
I dler no. 1 4
P to 1st (pivot to the first idler D) 0 1000000mm
P to 2
nd
(pivot to the second idler D) 0 1000000mm
（
see figure 3
—
3 and 3
—
11 for setup
）
Press “ PAGE DOWN ” soft key to enter the second page of the Scale Code Data Menu.
2006-3-21 12:00:00 Scale#1
SCALE CODE
DATA
1
P
to
L
： [ 1000mm ]
# of idlers ： [ 1 ]
P
to 1 st
：
[ 800mm ]
P
to 2 nd ： [ 800mm ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
SCALE CODE
DATA
2
P
to 3 rd ： [ 800mm ]
P
to 4 th ： [ 800mm ]
P
to 5 th ： [ 800mm ]
P
to 6 th ： [ 800mm ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
To Next Page
