36
Description Min Max
P to 3rd (Pivot to the third idler
distance)
0 1000000mm
P to 4th (Pivot to the forth idler D) 0 1000000mm
P to 5th (pivot to the fifth idler D) 0 1000000mm
P to 6th (pivot to the sixth idler D) 0 1000000mm
（
see figure 3
—
3 and 3
—
11 for setup
）
Press “ PAGE DOWN ” soft key to enter the third page of the Scale Code Data Menu.
Description Min Max
P to Test High (Pivot to test weight
height)
-500 500mm
P to Test Len (Pivot to test weight
length)
0 1000000mm
P to carry ( Pivot to carriage height) 0 1000000mm
R to carry ( Carry roll to carriage height ) 0 1000000mm
（ see figure 3 — 3 and 3 — 11 for setup ）
Press “ PAGE DOWN ” soft key from the Initial Setup 2 Menu or the previous menu to
enter ” Initial Setup 3 “ Menu as follows:
2006-3-21 12:00:00 Scale#1
SCALE CODE
DATA
3
P
to Test High ： [ 100mm ]
P
to Test Len ： [ 100mm ]
P
to carry ： [ 100mm ]
R to carry ： [ 100mm ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
INITIAL SETUP 3
# of Loadcells ： [ 1 ]
Idler Spacing ： [ 100mm ]
Conveyor Angle ： [ 10 ]
Loadcell Cap ： [ 100 kg ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
To Next Page
