37
Description Min Max
Load cell No. 1 8
Idler Spacing 0 10000mm
Conveyor Angle -25 25
Loadcell Cap. 0kg 1000000kg
（ see figure 3 — 2 and 3 — 11 for setup ）
Press “ PAGE DOWN ” soft key from the Initial Setup 3 Menu to enter the first page of Initial
Setup 4 Menu as follows:
Description Min Max
sensitivity 0 1000000
1#Resistance 0 1000000
2#Resistance 0 1000000
3#Resistance 0 1000000
Press “ PAGE DOWN ” soft key from the Initial Setup 4 Menu to enter the fifth page of
Initial Setup Menu 5 as follows:
2006-3-21 12:00:00 Scale#1
INITIAL SETUP 4
Sensitivity ： [ 3 mv/v ]
1#Resistor ： [ 350 Ohms]
2#Resistor ： [ 350 Ohms]
3#Resistor ： [ 350 Ohms]
Press
↑↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
INITIAL SETUP 5
4#Resistor ： [ 350 Ohms]
5#Resistor ： [ 350 Ohms]
6#Resistor ： [ 350 Ohms]
Weight Channel ： [ CHANNEL 1]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
