43
1 .9998 7 .9925 13 .9744
2 .9994 8 .9903 14 .9703
3 .9986 9 .9877 15 .9659
4 .9976 10 .9848 16 .9613
5 .9962 11 .9816 17 .9563
Measuring incline angle
m 、 Load cell size
From the belt scale data sheet located in the front of this manual, determine the load cell size
(example: 250.0). record the weight below:
kg （ load cell size ）
n 、 load cell sensitivity
From the nameplate of load cell, determine the load cell sensitivity in mV/V (example:
3.000mV/V)
Record below:
mV/V （ load cell sensitivity ）
o
、
load cell resistance
Measue each load cell ’ s output resistance using digital voltameter (example: 350.00)
Record below:
ohm
（
load cell resistance
）
p 、 Conveyor belt length, measure belt revolution one cycle length to the nearest 1mm with
tape measure.
Record below ：
mm
（
conveyor belt length
）
Press “ PAGE DOWN ” soft key from the Initial Setup 5 Menu, the sixth page of Initial Setup
Menu is displayed as follows:
The setting value of the speed mode are “ Simulated ” and “ Actual ” .
When “ Simulated ” is selected, the integrator will generate an analog signal for speed input.
2006-3-21 12:00:00 Scale#1
INITIAL SETUP 6
Speed Mode ： [SIMULATE ]
Speed Channel
：
[CHANNEL 1 ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
