Press “ SURE FACR ” to validate it.
Pressing “ EXIT FACR ” soft key enters the following screen Press
Pressing “ SURE SPAN ” soft key enters the following screen.
Press ing “ RUN ” soft key enters Run Menu.
Note: Belt scale calibration procedures
Belt scale calibration procedures consist of two parts: 1) initial calibration, 2) rutine
calibration
I nitial calibration need only be done once, various constants are needed for actual operation
of the system must be installed during initial calibration.
Routine calibration is performed by usning ZERO CAL and SPAN CAL procedures listed
under Main Menu 2.
These procedures are the fine adjustments used to compensate for material build-up,
mechnical wear, and uncontrollable conveyor parameters.
S ince most intallations differ in characteristics, Saimo recommends that a record be kept of
calibration results. T his will help to determine the frequency of calibration checks necessary
to maintain your accuracy requirements. S ee calibration report at the end of this section.
2006-3-21 12:00:00 Scale#1
8 000000 t
Old Span ： [ 888 ]
New Span ： [ 1000 ]
Material calibration complete ！
Span err ： [ -11.2% ]
BGIN EXIT MATL ADD ENTR
CAL CAL FACR REFR SPAN
2006-3-21 12:00:00 Scale#1
8 000000 t
888 t/h
1m/s
Material calibration complete ！
Span err ： [ -11.2% ]
BGIN MATL
CAL FACR
