66
Pressing ENT key enters the following screen.
As above menu, press “ SLCT ” , input port 1 switches between “ normal open ” and “ normal
close ” , when the proper input port1, for example “ NO ” is selected, then press “ ENTR ” to
confirm. The others are same as above in selection and operation.
Pressing “ PAGE DOWN ” soft key from the first page of I/O Definition 1 Menu enters the
second page of “ the I/O Definition Menu ” . This is the second page for Input Definition.
All menus operation is same as input port 1.
Pressing “ PAGE DOWN ” soft key enters the third page of the I/O Definition Menu.
2006-3-21 12:00:00 Scale#1
INPUTPORT SETUP 1
In port 1
：
[ NO DEFINE ] OPEN
In port 2 ： [ NO DEFINE ] [ OPEN ]
In port 3 ： [ NO DEFINE ] [ OPEN ]
In port 4 ： [ NO DEFINE ] [ OPEN ]
Press ENTR to select, then press SURE ！
MAIN SLCT ENTR PAGE
MENU DOWN
2006-3-21 12:00:00 Scale#1
INPUTPORT SETUP 2
In port 5 ： [ NO DEFINE ] [ OPEN ]
In port 6 ： [ NO DEFINE ] [ OPEN ]
In port 7 ： [ NO DEFINE ] [ OPEN ]
In port 8 ： [ NO DEFINE ] [ OPEN ]
Press
↑↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
OUTPUTPORT SETUP 1
Out port 1 ： [ NO DEFINE ] [ OPEN ]
Out port 2 ： [ NO DEFINE ] [ OPEN ]
Out port 3 ： [ NO DEFINE ] [ OPEN ]
Out port 4 ： [ NO DEFINE ] [ OPEN ]
Press
↑↓
key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
