All menus operation is same as input port 1.
The options of output port function include: “ Alarm 1 ” , “ Alarm 2 ” , “ Alarm 3 ” , “ Alarm 4 ” ,
“ Alarm 5 ” , “ Alarm 6 ” , “ Alarm 7 ” , “ Alarm 8 ” , “ No Define ” , “ Totalizer ” , “ Batch Start ” ,
“ Batch Complete ” , “ volumetric ” , “ cycle chain ” , “ ready ” , “ system failure ” . I nput /output
name is defined as per port function to be used.
Pressing “ PAGE DOWN ” soft key enters the fourth page of the I/O Definition Menu.
All menus operation is same as input port 1.
Pressing “ PAGE DOWN ” soft key enters the fifth page of the I/O Definition Menu.
All menus operation is same as input port 1.
Notes:
[BAT READY] is a pulse input signal. When the 6101 integrator receives this signal, a
measuring period for a batch of material is started.
[BAT RUN] is also a pulse input signal. Upon acceptance of this signal, the system switches
to start running status with the switch turning to BAT RUN.
When the discharged material is up to the target weight, Discharge End signal is sent from
the 6101 integrator.
When the measurement is up to the target weight, discharge signal is sent from the 6101
integrator.
If a port is not used, set it to [NO DEFINE].
2006-3-21 12:00:00 Scale#1
OUTPUTPORT SETUP 2
Out port 5 ： [ NO DEFINE ] [ OPEN ]
Out port 6 ： [ NO DEFINE ] [ OPEN ]
Out port 7 ： [ NO DEFINE ] [ OPEN ]
Out port 8 ： [ NO DEFINE ] [ OPEN ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
OUTPUTPORT SETUP 3
Out port 9
：
[ NO DEFINE ] [ OPEN ]
Out port 10 ： [ NO DEFINE ] [ OPEN ]
Out port 11 ： [ NO DEFINE ] [ OPEN ]
Out port 12 ： [ NO DEFINE ] [ OPEN ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
