SAJ R6 Series User Manual

R6 Series
- 14 -
R6-25K/30K/33K/36K-T3-32, R6-36K/40K/50K-T4-32
Model
R6-25K-T3-
32
R6-30K-T3-
32
R6-33K-T3-
32
R6-36K-T3-
32
R6-36K-T4-
32
R6-40K-T4-
32
R6-50K-T4-
32
Input (DC)
Max. PV Array Power
[Wp]@STC
37500
45000
49500
54000
54000
60000
75000
Max. Input Voltage [V]
1100
MPP Voltage Range [V]
180-1000
Nominal Input Voltage [V]
600
Startup Voltage [V]
200
Max. Input Current [A]
32/32/32
32/32/32/32
Number of MPP Trackers
3
4
Number of Strings per MPP
Tracker
2/2/2
2/2/2/2
Output (AC)
Rated AC Output Power [W]
25000
30000
33000
36000
36000
40000
50000
Max. Apparent Power [VA]
25000
33000
36300
39600
39600
44000
50000
Rated ACOutput Current
[A]@230Vac
36.2
43.5
47.8
52.2
52.2
58
72.5
Max. AC Output Current [A]
41.7
50
55
60
60
66.7
75.8
Nominal AC Voltage/ Range [V]
220(F-N)/380(F-F); 180-280(F-N)/312-485(F-F)
Nominal ACGrid Frequency/
Range [Hz]
50, 60 / 44-55, 55-65
Total Distortion Harmonic [THD]
<3%
Power Factor
0.8 leading～0.8 lagging
Feed-in Phase/AC Connection
Phases
3/3
Efficiency
Max. Efficiency
98.8%
Euro Efficiency
98.5%
Protection
DCI Monitoring
Integrated
GFCI Monitoring
Integrated
Grid Monitoring
Integrated
AC Grounding Detection
Integrated
AC Short-Circuit Protection
Integrated
DC Insulation Resistance
Detection
Integrated
DC Surge Protection
Type II
AC Surge Protection
Type III

SAJ R6 Series Specifications

General

Category	Inverter
Number of MPPTs	2
Protection Rating	IP65
THDi	< 3%
Cooling	Natural Convection
Communication	RS485, Wi-Fi, Ethernet
Rated AC Voltage	230V
AC Voltage Range	180 V - 280 V
Rated Grid Frequency	50 Hz / 60 Hz
Power Factor	0.8 leading - 0.8 lagging
DC Switch	Integrated
Protection	DC Reverse Polarity Protection, AC Short Circuit Protection
Operating Temperature Range	-25°C to 60°C
