Suntrio Plus Series
-
18
-
if necessary.
To make sure the installation spot is suitably ventilated, if multiple SAJ
on-grid solar inverters are installed together, the following safety clearance
in Figure 4.2 shall be followed for proper ventilation conditions.
30CM
30CM
30CM
50CM
50CM
50CM
80CM
30CM
30CM
50CM
50CM
50CM
50CM
50CM
50CM
50CM
50CM
50CM
80CM
80CM
80CM
80CM
80CM
Figure 4.2 Minimum clearance
