SAJ Suntrio Plus Series - 5.2 Specifications for Electrical Interface

Suntrio Plus Series
-
25
-
WARNING
·W
hen the photovoltaic array is exposed to light, it supplies a d.c voltage to the
inverter.
NOTICE
·Electrical connection should be
in conformity with proper stipulations, such as
stipulations for cross-sectional area of conductors, fuse and ground protection.
·The overvoltage category on DC input port is II,and that on AC output port is III.
5.2 Specifications for Electrical Interface
Figure 5.1 Suntrio Plus-12/ 15/ 17/ 20K electrical interface
Code
Name
A
DC Input
B
RS232/Wi-Fi Port
C
Decompression valves
D
AC output
E
RS485 port
F
Ground Connecting port
