DC Switch
Table 5.1 Specifications for Suntrio Plus-12/ 15/ 17/ 20K interface
Figure 5.2 Suntrio Plus-25/ 33K electrical interface
Code
Name
A
DC Input
B
RS232/Wi-Fi Port
C
Decompression valves
D
AC output
E
RJ45 Port
F
Ground Connecting port
G
DC Switch
Table 5.2 Specifications for Suntrio Plus-25/ 33K interface
