5
Figure 3.1
3.2 Safety Clearance
Please follow up the safety clearance below when install one or multiple SAJ Solar Inverter.
Please contact SAJ for more installation information.
Direction
Minimum Clearance（cm）
Above 30
Below 50
Side 50
Front 5
Figure 3.2
3.3 Mounting Procedure.
1) Use the rear panel in the package as a drilling template and mark the positions of the drill
holes, as illustrated below.
Install on the wall correctly.
