Sakura Tissue-Tek AutoTEC - Page 53

TROUBLESHOOTING
6.4 Revised 5/19/2010
28
HEATER
TEMPERATURE
PROBLEM
FRAME HEATER OUT OF
RANGE
The Frame Heater temperature [##] is out of acceptable
range [Min: ##, Max:##]
Please empty all input & output doors and contact Sakura
Service Department for further instructions.
Please touch RESUME to restart the application or
ABORT to shutdown the instrument.
Perform action/s
requested
29
HEATER
TEMPERATURE
PROBLEM
FRAME HEATER RTD IS
OPEN
The [GRIPPER FRAME HEATER] RTD is Open.
The instrument MUST be serviced before embedding can
continue.
Touch OK
33
REQUEST
OUTPUT DOOR #<1–4> IS
NOT EMPTY
Please empty Output Door #<1–4>, then touch OK to
resume instrument operation.
Touch OK
35
CASSETTE/
BLOCK PROBLEM
DROPPED
CASSETTE/BLOCK INSIDE
THE INSTRUMENT
A cassette/block might have been dropped inside the
instrument. Please open front door and ifrequired, back doors
and inspectfor any dropped cassette/ block and retrieve
it.
Close all the doors and please touch OK when done.
Touch OK
36
MISSING CASSETTE
NO CASSETTE DETECTED IN FRAME
Chute message
displayed
37
38
MISSING CASSETTE
NO FRAME DETECTED IN GRIPPER
Chute message
displayed
39
FRAME
POSITION
PROBLEM
PARAFORM CASSETTE
INCORRECTLY
POSITIONED IN BASE
MOLD
Open the front door and reset the Paraform Cassette in
base mold #<1-8> [cassette type]. Once the cassette has
been reset, close and latch the front door then touch OK to
resume instrument operation.
Touch OK
41
MISSINGBLOCK
PROBLEM
BLOCK NOT REMOVED
FROM BASE MOLD
Open the front door and, if necessary, the rear doors and
retrieve the missing block from base mold #<1-8>.
Remove any excess paraffin or obstruction around the
base mold. Once the block has been retrieved, close and
latch all doors, then touch OK to resume instrument
operation.
Touch OK
42
MISSINGBLOCK
PROBLEM
MISSING BLOCK FROM
BASE MOLD
Touch OK
45
U/V STEPPER
BOARD
PROBLEM
U/V STEPPER BOARD NOT
RESPONDING
U/V Stepper Board is not responding. System is trying to
recover the error to resume current operation
Error Log
46
W/X STEPPER
BOARD
PROBLEM
W/X STEPPER BOARD NOT
RESPONDING
W/X Stepper Board is not responding. System is trying to
recover the error to resume current operation
Error Log
47
Y/Z STEPPER
BOARD
PROBLEM
Y/Z STEPPER BOARD NOT
RESPONDING
Y/Z Stepper Board is not responding. System is trying to
recover the error to resume current operation
Error Log
48
SOLENOID
DRIVER BOARD
PROBLEM
SOLENOID DRIVER BOARD
NOT
RESPONDING
The Solenoid Driver Board is not responding. Please
contact Sakura Service department for further
instructions.
Please remove all input magazines and empty all output
doors then touch OK to shut down the system.
Instrument shuts
down if [OK] is
touched
49
HEATER
CONTROLLER
BOARD
PROBLEM
HEATER CONTROLLER
BOARD NOT
RESPONDING
The Heater Controller Board is not responding. Please
contact Sakura Service department for further
instructions.
Please remove all input magazines and empty all output
doors then touch OK to shut down the system.
Instrument shuts
down if [OK] is
touched
50
TEC BOARD
PROBLEM
TEC BOARD NOT
RESPONDING
The TEC Board is not responding. Please contact Sakura
Service department for further instructions.
Please remove all input magazines and empty all output
doors then touch OK to shut down the system.
Instrument shuts
down if [OK] is
touched
51
INPUT DOOR
PROBLEM
INPUT DOOR BOARD NOT
RESPONDING
Input Door Stepper Board is not responding. System is
trying to recover the error to resume current operation
Error Log
