Revised 5/19/2010 6.5
52
FRAME HEATER
MOTOR PROBLEM
BOTH THE LIMIT
SWITCHES OF FRAME
HEATER MOTOR ARE
TRIGGERED
Unable to move Frame Heater. Both the limit switches are
triggered.
Please empty all input & output doors and contact Sakura
Service Department for further instructions.
Instrument shuts
down if [OK] is
touched
53
I/O BOARD
PROBLEM
I/O BOARD NOT
RESPONDING
The I/O Board is not responding. Please contact Sakura
Service department for further instructions.
Please remove all input magazines and empty all output
doors then touch OK to shut down the system.
Instrument shuts
down if [OK] is
touched
54
BASEMOLD
PROBLEM
TEC DISABLED
Base mold #<1-8> has been disabled due to <High-
Low><Heating-Cooling><Temperature> on <Cassette
Type>
Error Log
55
BASEMOLD
PROBLEM
THERE HAVE BEEN THREE
CONSECUTIVE V AXIS
STALLS ON A PARTICULAR
BASE MOLD
Initiate the process to disable the particular base
mold. Abort the process by touching on ABORT or
expedite the current process by touching on RESUME. A
timed message box appears for the user to act upon, after
180 seconds and no response from the user, it will disable
the particular base mold and continue working with the
next cassette and base mold.
Touch RESUME to
disable or touch
ABORT to continue
current operation
without disabling the
base mold.
3 CONSECUTIVE ABORT
COMMANDS ON BASE
MOLD SELECTED
The user selected three consecutive ABORT commands
on base mold #<1-8>. System will now disable base mold
#<1-8>
Touch OK
BLOCK NOT REMOVED
FROM BASE MOLD
Base mold #<1-8> disabled due to block not removed.
Error Log
56
NON-
RECOVERABLE
ERROR
INSTRUMENT
EXPERIENCES 3
CONSECUTIVE STALLS
WITHIN 20 MINUTES
The instrument has experienced a non-recoverable error
with the [U/V]][W/X][Y/Z] [Input Door] Stepper.
Please remove all input magazines and empty all output
doors, instrument will now shut down.
Contact Sakura Service Department for further
instructions.
Contact Sakura
Service Department
57
MAGAZINE
PROBLEM
MAGAZINE NOT SEATED
Input Magazine(s) #n not seated properly. Please reseat
these magazines. Touch OK to open input door now.
Touch OK
58
MAGAZINE
PROBLEM
UNABLE TO HOLD
CASSETTE FROM INPUT
DOOR
Check magazine (#) for cassettes. NOTE: Removing
magazine will cause the magazine to warm up for 15
minutes. Do not remove any other magazines.
Touch ABORT to
open input door and
check magazine (#).
Touch RESUME to
continue with the
current cycle. User
has 60 seconds to
respond to message.
59
SENSOR
MALFUNCTION
SENSOR CHECK
The following sensors are not function properly:
……………
Failed sensor check.
Please contact Sakura Service Department for further
instructions.
Touch OK
61 CASSETTE IMPROPER ASSEMBLY CASSETTE LID OPENED IN FRAME
62 CASSETTE IMPROPER ASSEMBLY
CASSETTE TABS PUSHED DOWN IN FRAME AT
CASSETTE TYPE CHECK
Chute message
displayed
63
RUN ABORTED
WARNING
OPEN LID DETECTED
Please open the front door and close cassette lid on base
mold #X Standard
Then touch RESUME to continue current process OR
touch ABORT if more time is needed.
To prevent base molds and cassettes from being damaged,
instrument will continue embedding and clear all base
molds (except base mold #X) and stop embedding in 180
seconds.
Touch ABORT or
RESUME
64
MAINTAINENCE
CLEAN SPLASH GUARD,
GRIPPER & ID PANEL
Maximum number of cassettes-to-embed exceeded
(1000), must clean splash guard, gripper, BM covers, ID
back openings.
Touch OK
