SALMSON 08/2016
Connection to mains supply Power terminals
Connect the 4 wires cable on the power terminals
(phases + earth).
Connection of inputs / outputs Inputs / outputs terminals
• The sensor, external setpoint and [ext.off] inputs cable
must be necessarily screened.
• The remote control allows the switching On or Off of the
pump (free contact), this function has priority on the others.
• This remote control can be removed by shunting the ter-
minals (3 and 4).
Example: Float switch, pressure gauge for dry-running…
Connection terminals of the interface
PLR The optional IF-Module PLR is to be pushed into the mul-
tiplug in the connection area of the converter.
The connection is twist-proof.
LON The optional IF-Module LON is to be pushed into the
multiplug in the connection area of the converter.
The connection is twist-proof.
L1 L2 L3
GND...
In2...
In1...
Remote
control
ON/OFF
External Set value
Sensor 20mA/10V
Not used Not used
GND...
+24V...
1
2
3
4
5
6
7
8
9
10
11
aux
ext.off
MP
20mA/10 DDS
