There are few user controls for the ST620RF, making the
programmable thermostat very easy to operate. The controls are
a Touch Ring (which surrounds the user display), two touch
sensitive buttons, a reset button and a slide operated switch
mounted on the side of the thermostat. The ST620RF Receiver has
only two slide switches, a Sync button and a Reset button.
These controls are shown below, along with a description of each
of their functions.
USER CONTROL FUNCTION SUMMARY:
Key / Operation Functions
Touch Ring (move clockwise) Increases the selected setting and scrolls
down the menu selection
Touch Ring (move anti- clockwise) Decreases the selected setting and
scrolls up the menu selection
OK Key Enters Menu or confirms a menu selection
Arrow (Back) Key Single touch – sets the unit back one step.
Hold for two seconds sets the unit back to NORMAL mode
Reset Button Resets the programmable thermostat to default (original factory)
settings except Service setting (when Service is on)
Slide Switch Activates and deactivates the key lock function
(prevents accidental changes)
ST620RF INSTRUCTION MANUAL16
