1.3 ACCESS TO THE PREMISES
The dimensions of the fully assembled oven are as follows:
OVEN Front (mm) (feet/inches) Depth (mm) (feet/inches) Height (m) (feet/inches)
SP-21-C 2.258 / 7’4” 1.877 / 6’2” 2.197 / 7´2”
SP-22-C 1.760 / 5´9” 2.250 / 7´5” 2.197 / 7´2”
SP-23-C 1.760 / 5´9” 2.250 / 7´5” 2.197 / 7´2”
SR-21-C 2.023 / 6’8” 1.640 / 5,5” 2.197 / 7´2”
SR-22-C 1.582 / 5´2” 2.031 / 6´8” 2.197 / 7´2”
SR-23-C 1.582 / 5’2” 2.031 / 6´8” 2.197 / 7´2”
SK-21-C 1.665 / 5´6” 1.405 / 4´7” 2.197 / 7´2”
SK-22-C 1.275 / 4´2” 1.705 / 5´7” 2.197 / 7´2”
SK-23-C 1.275 / 4´2” 1.705 / 5´7” 2.197 / 7´2”
The dimensions of the largest part of the disassembled oven are as follows:
Dimensions (mm)
(feet/inches)
SP-21-C
SP-22-C
SP-23-C
SR-21-C
SR-22-C
SR-23-C
SK-21-C
SK-22-C
SK-23-C
Length
1.501 / 4´11” 1.292,5 / 4´3” 1.090,5 / 3´7”
Width
936 / 3´8” 857 / 2´10” 734 / 2´5”
Height
2.064,5 / 6´9” 2.064,5/ 6´9” 2.064,5 / 6´9”
The assembled oven is fitted with lifting eyes, for its unloading with a crane and positioning on site.
The net weight of the assembled ovens are as follows:
SP-21-C
SP-22-C
SP-23-C
SR-21-C
SR-22-C
SR-23-C
SK-21-C
SK-22-C
SK-23-C
Weight Kgs.
Lbs.
1.750
3.858
1.650
3.638
1.300
2.866
