Salva SIROCCO 2000 - ELECTRICAL CONNECTION; GAS INSTALLATION

SALVA INDUSTRIAL, S.A Horno Sirocco 00 Gas-Gasoil 50-60Hz (ing)121206.doc
1-5
1.5 ELECTRICAL CONNECTION
This should be carried out by authorized professionals according to regulations in the country in
question. The electrical installation and the motors should be ventilated.
Admissible allowance between rated (230V or 400V) and real voltage is ± 10% as a maximum.
Full power of the ovens and the so the maximum consumption that bears the electrical system
are as follows:
Power (kW) Consumption at 230 V (A) Consumption at 400 V (A)
SP-21-C
SP-22-C
SP-23-C
1 3,5 2
SR-21-C
SR-22-C
SR-23-C
1 3,5 2
SK-21-C
SK-22-C
SK-23-C
0,5 2,5 1,5
Wire sections recommended by SALVA INDUSTRIAL, S.A., following the EN 60204-1
requirements for the electrical installation with PVC isolated wires, are shown on the table below:
Sections at 230 V (mm
2
) Sections at 400 V (mm
2
)
R S T PE R S T PE
N (neutral)
SP, SR, SK 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
1.6 GAS INSTALLATION
This should be carried out by authorized professionals according to regulations in the country in
question. The maximum available power which can be withstood by the oven construction is as
follows:
SP-21-C
SP-22-C
SP-23-C
SR-21-C
SR-22-C
SR-23-C
SK-21-C
SK-22-C
SK-23-C
Max. Power (KW – Kcal./h) 96 - 82944 67 - 57888 49 - 42336
