28
Transmission Switch Selector.
The four driving modes are:
1. Road - maximum speed but with reduced motor torque.
2. Maximum Tractive effort - all wheel motors with full power capability - generally only
Suitable on flat land.
3. Conventional Spraying - used for flat land, steep uphill and moderate downhill spraying.
gives best overall performance.
4. Steep downhill - this mode provides the best control when descending a steep hill when
traction is marginal. If mode 3 is being used and the rear wheels begin to skip, mode 4 may
be selected on the move.
Remember: if the machine will not climb the hill in Mode 3, never attempt to descend
the hill
The vehicle has a permanent four-wheel drive system but this is only relevant when all wheels can provide tractive
effort.
MACHINE CONTROLS 3000, 3000E & 3500
Armrest Control console
2.2-3
