Sam Horizon - Fuse and Relay Identification

64
DUAL
RIDE
VALVE
RELAY
4WS
VALVE
RELAY
DEUTZ
NEUTRAL
START
RELAY
HORN
RELAY
L/H
INDICATOR
JOYSTICK
RELAY
R/H
INDICATOR
JOYSTICK
RELAY
SPRAY
CONTROLLER
TIMER
RELAY
HYD
SLIDING
AXLES
STEERING
CUT OFF
RELAY
SPRAY CONTROLLER
SECONDARY 5A (PERM)
REVERSE LIGHTS
5A
SIDE LIGHTS
3A (PERM)
DUAL RIDE
5A
MAIN BEAMS
10A
OPT. FLOW METER
7.5A
HAZARDS
10A (PERM)
4WS VALVE
5A
UREA TANK
5A
L/R INDICATORS
10A
SPRAY CONTROLLER
PRIMARY 25A (PERM)
OPT. STOCKS
(SINGLE 20A)
ARM REST CONSOLE
5A (PERM)
OPT. GEO STEER
5A
BOOM LEVELLING
15A (PERM)
OPT. SIMPLE
WASH DOWN 15A
OPT. BOUT MARKER
5A
STEERING COLUMN
5A (PERM)
STOP/BRAKE LIGHTS
5A
UREA TANK 15A
4WS SENSOR
2A
DIPPED BEAMS
10A
DAY RUNNING LIGHTS
3A
EGR
5A
POCLAIN ECU
25A
WIPERS
10A
4WS SENSORS
2A
NOX SENSORS
15A
ARM REST CONSOLE
5A
HORN & WASHERS
10A
HORN
7.5A
DEUTZ ENGINE ECU
30A (PERM)
Electronic Dash
5A
Rear Work
Lights
30A
Radio
7.5A
Front Work
Lights
30A
Radio (Perm)
15A
Beacons
15A
Fans
30A
Interior Light
5A
Cool Box +
Cig Socket
20A
Mirror Adjustment +
Heaters
5A
Climate Control
Unit
5A
Additional Fans
5A
Air Conditioner
Compressor
5A
Wiper
15A
Electronic Dash
(perm) 5A
Seat
Compressor
15A
Rear
Work
Lights
Relay
Mirror
Heaters
Relay
Front
Work
Lights
Relay
Spare
Relay
Spare
Relay
Beacons
Relay
Spare
Relay
Wiper
Relay
FUSES & RELAYS
6.1-6
Over Head Compartment
Right Hand Lower Compartment
