SAME SOLARIS 45 User Manual

SECTION III USE
Safety frame
The safety frame can be tilted forwards.
Remove the pin from hole A and tilt the safety frame forwards.
Engage the pin in hole B to
lock the safety frame in
lowered position (see next
page).
Only operate the tractor
with the safety frame down
when strictly necessary for
specific farming tasks.
Removing the pin to release
and tilt the safety frame.
76
WARNING: IF THE TRACTOR IS EQUIPPED WITH A FOLD DOWN
ROPS, DO NOT WEAR SEAT BELT WHEN THE ROPS IS IN THE
FOLDED DOWN POSITION FOR A SPECIFIC OPERATION. WEAR
SEAT BELT AGAIN WHEN THE ROPS IS ERECTED.

SAME SOLARIS 45 Specifications

General

Engine Power	45 hp
Hydraulic System	Open center
Drive	4WD
PTO Power	38 hp
Hydraulic Remotes	2
Engine Type	Diesel
PTO	540 rpm
Displacement	2.9 liters
Tire Size - Front	7.5-16
