SECTION IV WHEELS
Track width adjustment for wheels with fixed rims
In this case only two fitting methods, A and B, are possible for the front and
rear wheels, as shown in the figure.
Front wheels
Rear wheels
The following wheels have fixed rims:
–
7.00-12 front
–
31x13.50-15 front
–
44x18.00-20 rear
–
13.6-16 rear
–
260/70R16 front
–
320/70R24 rear
104
A
B
A
B
