SAME SOLARIS 45 User Manual

SECTION V MAINTENANCE
Maintenance of front lift
The lower links of the front lift can be removed if required by removing the 2
safety pins and pivot pins shown in the figure. For driving on public roads,
the front lift links must be secured in raised position by means of the link
pins and support.
149
DANGER: THE DRIVEN IMPLEMENTS COULD ROTATE FOR SOME
TIME AFTER P.T.O. HAS BEEN DISENGAGED. PLEASE STOP THE
TRACTOR ENGINE AND WAIT UNTIL ALL THE MOVING PARTS OF
IMPLEMENT HAVE COME TO A COMPLETE STANDSTILL, BEFORE
TO START ANY SERVICING OPERATION.

SAME SOLARIS 45 Specifications

General

Engine Power	45 hp
Hydraulic System	Open center
Drive	4WD
PTO Power	38 hp
Hydraulic Remotes	2
Engine Type	Diesel
PTO	540 rpm
Displacement	2.9 liters
Tire Size - Front	7.5-16
