SECTION I SAFETY/DECALS/SYMBOL
9 - P/N 2.9929.304.0/10
Location: On carter of protection of rear P.T.O.
10 - P/N 2.9929.856.0
Location: On the left fender (rear of the platform)
LI
2.9929.304.0/10
READ OPERATOR MANUALS FOR COMPLETE INSTRUCTIONS AND SAFE
35 mm (1.38 IN.)
R.P.M. P.T.O. SHAFT.
1.
406 mm (16.0 IN.)
1000
4.
LOCK DRAWBAR IN LINE WITH P.T.O. OUTPUT SHAFT.
35 mm (1.38 IN.)
1000
SHAFT SIZE DISTANCE "A"
2.
45 mm (1.75 IN.)
5.
POSITION IMPLEMENT P.T.O. DRIVELINE IN LINE WITH DRAWBAR.
POSITION DRAWBAR HITCH HOLE AS FOLLOWS:
356 mm (14.0 IN.)
3.
508 mm (20.0 IN.)
540
RPM
PTO
DO NOT OPERATE P.T.O. ABOVE RATED SPEED FOR 540 OR 1000
OPERATION TO AVOID ACCIDENTS.
2.9929.856.0
linkage at orizontal
position or below
Pull only from
approved drawbar or
lower links of 3 point
in place during operation
and equipment shields
keep all driveline, tractor
or death
may cause serious injury
Rotating driveline contact
DANGER
DANGER
