Index revision : H 11 6336
In the case of a manual unit connected to an industrial PLC:
In this case, the spray gun is connected to the PLC via the “PLC plug.” The following parameters must
be entered on start-up.
The communication speed is selected from the following list: 1,200, 2,400, 4,800, 9,600, 14,400,
18,200 and 38,400 baud.
Parameters Factory value Minimum Maximum
Remote mode - Slave index
1
199
Remote mode - Communication speed
9,600 baud
1,200 baud 38,400 baud
Auxiliary EV action synchronised with the
trigger
0
01
G
Front of CRN 457 module
manual unit with PLC connection
