Sames Mach-Jet - 4.1. Module Connections; 4.2. Module Identification Plate

Index revision : H 12 6336
4.1. Back of “CRN 457” control module
4.1.1. Module connections
4.1.2. Module identification plate
Start/stop
switch
Pneumatic output (auxiliary)
Vibrating table/tank
Pneumatic output
“Dilution”
General power supply
Base plate A
“Spray gun plug”
Ground
terminal
Mains
cable
Pneumatic output
“Injection”
Base plate B
“PLC plug”
Module serial
number
Module program version
2005 - S48 00445
Wrk 2.07 - S37
