Sames Mach-Jet - Page 40

Index revision : H 40 6336
Item P/N Description Qty
Unit
of
sale
First
Emer-
gency
Consu
mable
1524463 Mach-Jet Spray Gun 1 1 - -
1524463-12
Mach-Jet spray gun assembly (with
12-m cable)
11 - -
1524463-18
Mach-Jet spray gun assembly (with
18-m cable)
11 - -
1 1524464 Gun assembly (see § 10.2 page 41) 11 - -
2 1525492
Fan spray nozzle assembly
(see § 10.5.1 page 44)
11X
3 1313519
Medium fan spray deflector
(see § 10.5.1 page 44)
1 1 or 10 X
4 1311739 Nozzle nut 1 1 X
5 1525493
Round spray nozzle assembly
(see § 10.5.2 page 44)
11 X
6 1411993 Round spray deflector, Dia.: 25 mm 1 1 X
7 X3GJCP004
Screw PT KA25x6 WN1412 galvanised
steel, cross-head
21 - -
8 1524468 Electronic board 1 1 - -
9 J2FTCS435 O-ring - silicone 1 1 - -
10 X3GJBP484
Screw PT KA30x20 WN1411 galvanised
steel, cross-head
71X
11 J4BRND039 Fibre seal 7 1 X
12
1524465 Cable assembly (length: 6m) 1 1 X
1526699 Cable assembly (length: 12m) Option 1X
910004244 Cable assembly (length: 18m) Option 1X
13 U1FGBA092 Powder hose 11 x 15 6 m X
14 1411501 Powder connector assembly 1 1 or 10 X
15 1525793
Vertical powder pipe assembly
see § 10.4 page 43
11X
16 1525908 Handle assembly (see § 10.3 page 42) 11 - -
17 1313078
“Small-size” hand-rest (included in item
16)
11 - -
18 1313349 “Large-size” hand-rest Option 1- -
