APPENDIX A
SECTION 4 | Parameter Setup
4.4 GROUP 1 PARAMETER SET UP: CHARGE CURVE
Please refer to Parameters under Group 1 at Fig 4.1. Details of Parameter set up are given below:
TABLE 4.4. GROUP 1 PARAMETER SET UP: CHARGE CURVE
Page
No. for
Group
1 (Fig
4.1)
Parameter
Programming Range Default
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
1 “BULK CURRENT”
(Bulk Charge Current
“Io”)
0 – 100A 0 – 130A 0 – 70A 0 – 110A 40A
2 “ABSORP VOLTAGE”
(Absorption Voltage)
13.5V – 16.0V 27.0V – 32.0V 14.4V 28.8V
3 “EQUALIZE VOLTAGE”
(Equalization Voltage)
14.0V – 16.0V 28.0V – 32.0V 14.4V 28.8V
4 “FLOATING VOLTAGE"
(Float Voltage)
13.0V – 15.0V 26.0V – 30.0V 13.5V 27.0V
5 “COMPENSATE”
(Temperature
Compensation)
-3mV to -5mV /°C/Cell -4mV /°C/Cell
6 “BATT OVER VOLT”
(Battery Over Voltage
Shut Down)
14.0V – 17.0V 28.0V – 35.0V 16.0V 32.0V
7 “RESET VOLTAGE”
("Battery Low
Voltage!") Reset
12.0V – 17.0V 24.0V – 35.0V 14.0V 28.0V
8 “LOW VOLT ALARM”
(Battery Low Voltage
Alarm)
9.5V – 12.5V 19.0V – 25.0V 11.0V 22.0V
9 “BATT LOW VOLTAGE”
(Battery Low Voltage
Shut Down)
9.1V – 12.0V 18.1V – 24.0V 10.5V 21.0V
10 “LV DETECT TIME”
(Detect Time to
Qualify as "Battery
Low Voltage" Shut
Down Condition)
0-600 sec 10 sec
11 “LV CUT OFF TIME”
(Time in pre Low Volt-
age Shut Down Condi-
tion (No AC output)
before complete shut
down is activated)
0-7200 sec 1200 sec
