18 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 19
APPENDIX A
SECTION 4 | Parameter Setup
12 “CHARGE MODE”
(3 or 4 Stage Charging)
Normal (3-Stage) /
Equalization (4-Stage)
0 = Normal (3-Stage)
13 "ONLINE MODE" or
"OFFLINE MODE"
0 = Off (Off-Line : Grid priority)
1 = On (On-Line: Battery/Inverter priority)
0 = Off
14 "RECONNECT VOLT"
(For On-Line Mode)
0 = Option 1
1 = Option 2
0 = Option 1
15 "FLOATING EXIT" 10.00V – 13.00V 20.00V – 26.00V 12.00V 24.00V
16 GS DETECT TIME 0 - 600 sec 10 sec
17 GEN ON TIME 0 - 240 min 60 min
18 GEN OFF 0 - 240 min 60 min
BULK CURRENT:
This sets the maximum charging current of EVO Inverter Charger. This value is the sum of
charging currents from the internal AC Charger and external Charge Controller connected to
the EXT. Charger terminals of EVO Inverter Charger (3,4 Fig 2.1 in Owner's Manual for EVO
Inverter Charger).
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
Enter Key
ò
ABSORP VOLTAGE:
This sets the charging voltage in the Constant Voltage Absorption Stage.
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
ABSORP VOLTAGE
14.40 V
Enter Key
ò
Up Key x 1
ò
EQUALIZE VOLTAGE:
This sets the charging voltage in the Constant Voltage Stage in the 4-stage Equalization
Charging Stage.
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
EQUALIZE VOLTAGE
14.40 V
Enter Key
ò
Up Key x 2
ò
FLOATING VOLTAGE:
This sets the charging voltage in the Constant Voltage Float Stage.
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
FLOATING VOLTAGE
13.50 V
Enter Key
ò
Up Key x 3
ò
COMPENSATE:
This parameter sets the temperature compensation for the battery. The operational range of
the EVO Inverter Charger is -20°C to 60°C.
