APPENDIX A
SECTION 4 | Parameter Setup
4.6 GROUP 3 PARAMETER SET UP: INPUT LOW LIMIT
Please refer to Parameters under Group 3 at Fig 4.1. Details of Parameter set up are given below:
TABLE 4.6. GROUP 3 PARAMETER SET UP: INPUT LOW LIMIT
Page
No. for
Group
3 (Fig
4.1)
Parameter
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
1 RESET VOLTAGE 60.0 – 100.0V 95.0V
2 CUT OFF VOLT 1 60.0 – 100.0V 90.0V
3 DETECT TIME 1 0 – 2000 cycles 300 cycles
4 CUT OFF VOLT 2 60.0 – 100.0V 85.0V
5 DETECT TIME 2 0 – 2000 cycles 60 cycles
6 CUT OFF VOLT 3 60.0 – 100.0V 80.0V
7 DETECT TIME 3 0 – 2000 cycles 1 cycle
RESET VOLTAGE:
This is the reset voltage at which the unit will revert to "Charging Mode" after it has
switched over to "Inverting Mode" due to input voltage falling to "CUT-OFF VOLT 1/CUT-OFF
VOLT 2/CUT-OFF VOLT3".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
CUT OFF VOLT 1:
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 1" for period >
"DETECT TIME 1", the EVO Inverter Charger will transfer to Inverting Mode from "Charging
Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
CUT OFF VOLT 1
90.0 V
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 1
ò
DETECT TIME 1:
This is the time limit in cycles up to which low AC input voltage "CUT-OFF VOLT 1" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
DETECT TIME 1
300 cycles
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 2
ò
CUT OFF VOLT 2:
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 2" for period >
"DETECT TIME 2", the EVO Inverter Charger will transfer to "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
CUT OFF VOLT 2
85.0 V
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 3
ò
