APPENDIX A
DETECT TIME 2:
This is the time limit in cycles up to which low AC input voltage "CUT-OFF 2" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
DETECT TIME 2
60 cycles
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 4
ò
CUT OFF VOLT 3:
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 3" for period >
"DETECT TIME 3", the EVO Inverter Charger will transfer to "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
CUT OFF VOLT 3
80.0 V
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 5
ò
DETECT TIME 3:
This is the time limit in cycles up to which the low AC input voltage "CUT-OFF 3" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT LOW LIMIT
DETECT TIME 3
1 cycle
RESET VOLTAGE
95.0 V
Up Key x 2
ò
Enter Key
ò
Up Key x 6
ò
4.7 GROUP 4 PARAMETER SET UP: INPUT HIGH LIMIT
Please refer to Parameters under Group 4 at Fig 4.1. Details of Parameter set up are given below:
TABLE 4.7. GROUP 4 PARAMETER SET UP: INPUT HIGH LIMIT
Page
No. for
Group 4
(Fig 4.1)
Parameter
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
1 RESET VOLTAGE 100.0 – 150.0V 135.0V
2 CUT OFF VOLT 1 100.0 – 150.0V 140.0V
3 DETECT TIME 1 0 – 2000 cycles 60 cycles
4 CUT OFF VOLT 2 100.0 – 150.0V 145.0V
5 DETECT TIME 2 0 – 2000 cycles 15 cycles
6 CUT OFF VOLT 3 100.0 – 150.0V 150.0V
7 DETECT TIME 3 0 – 2000 cycles 1 cycle
RESET VOLTAGE:
This is the reset voltage at which the unit will revert to "Charging Mode" after it has switched
over to "Inverting Mode" due to input AC voltage rising to "CUT-OFF VOLT 1/CUT-OFF VOLT 2/
CUT-OFF VOLT 3.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
SECTION 4 | Parameter Setup
