30 | SAMLEX AMERICA INC.
APPENDIX A
CUT OFF VOLT 1:
If during "Charging Mode", the AC input voltage rises above "CUT-OFF VOLT 1" for period >
"DETECT TIME 1", the EVO Inverter Charger will transfer to "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
CUT OFF VOLT 1
140.0 V
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 1
ò
DETECT TIME 1:
This is the time limit in cycles up to which high AC input voltage "CUT-OFF VOLT 1" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
DETECT TIME 1
60 cycle
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 2
ò
CUT OFF VOLT 2:
If during "Charging Mode", the AC input voltage rises above "CUT-OFF VOLT 2" for period >
"DETECT TIME 2", the EVO Inverter Charger will transfer to "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
CUT OFF VOLT 2
145.0 V
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 3
ò
DETECT TIME 2:
This is the time limit in cycles up to which high AC input voltage "CUT-OFF VOLT 2" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
DETECT TIME 2
15 cycle
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 4
ò
CUT OFF VOLT 3:
If during "Charging Mode", the AC input voltage rises above "CUT-OFF VOLT 3" for period >
"DETECT TIME 3", the EVO Inverter Charger will transfer to "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
CUT OFF VOLT 3
150.0 V
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 5
ò
DETECT TIME 3:
This is the time limit in cycles up to which high AC input voltage "CUT-OFF VOLT 3" is allowed.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
INPUT HIGH LIMIT
DETECT TIME 3
1 cycle
RESET VOLTAGE
135.0 V
Up Key x 3
ò
Enter Key
ò
Up Key x 6
ò
SECTION 4 | Parameter Setup
