4.8 GROUP 5 PARAMETER SET UP: OTHER FUNCTIONS
Please refer to Parameters under Group 5 at Fig 4.2. Details of Parameter set up are given below:
TABLE 4.8. GROUP 5 PARAMETER SET UP: OTHER FUNCTIONS
Page
No. for
Group 5
(Fig 4.2)
Parameter
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
1 POWER SAVING 1 = Enable 0 = Disable 1 = Enable
2 ENTER POINT 4 – 50W 6W 8W 6W 8W
3 WAKE UP POINT 5 – 50W 7W 10W 7W 10W
4 REMOTE SWITCH
0 = Button Type
1 = Switch Type
Button type
5 RELAY FUNCTION
0 = Charge/Other
1 = Normal/Fault
2 = Generator 0
3 = Generator 1
4 = Generator 2
2 = Generator 0
6 COMM ID 1 – 255 1
7 BUZZER
1 = ON
0 = OFF
1 = ON
8 DISCHARGE BEEP
1 = ON
0 = OFF
0 = OFF
9 DEFAULT RESET
0 = No
1 = Yes
0 = No
10
DATALOG DISABLE
DATALOG TIME
0 = Disable, 1 = 1 sec,
2 = 10 sec, 3 = 30 sec
4 = 1 min, 5 = 5 min, 6 = 10 min
1 = 1 sec
11 PARAMETER SAVE
0 = No
1 = Yes
0 = No
POWER SAVING:
Enable or disable Power Saving Mode when in "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
ENTER POINT:
If the value of power drawn by AC load falls to the "ENTER POINT" value for 5 sec, the unit
will enter "Power Save Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
ENTER POINT
6W / 8W
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 1
ò
