 Batteries generate Hydrogen and Oxygen during charging resulting in evolution of
explosive gas mixture. Care should be taken to ventilate the battery area and follow
the battery manufacturer’s recommendations.
 Never smoke or allow a spark or ame near the batteries.
 Use caution to reduce the risk of dropping a metal tool on the battery. It could spark
or short circuit the battery or other electrical parts and could cause an explosion.
Always use insulated tools.
 Remove metal items like rings, bracelets and watches when working with batteries.
Batteries can produce a short circuit current high enough to weld a ring or the like to
metal and thus cause a severe burn.
 If you need to remove a battery, always remove the Ground terminal from the battery
rst. Make sure that all the accessories are off so that you do not cause a spark.
TABLE 1.1(a) SIZING OF GRID AND GENERATOR INPUT WIRING AND BREAKERS (FOR DEFAULT INPUT
CURRENT LIMIT PROGRAMMED AT 30A FOR EVO-2212, EVO-2224, EVO-3012, EVO-4024)
Model No. and
Rated Output
Power in In-
verter Mode
(Column 1)
Rated
AC Pass
Through
Current
(See Note
1)
(Column 2)
Rated AC
Charging
Current
(See Note
2)
(Column 3)
Total Rated
AC Input
Current
(Columns
2 +3)
(See Note 3)
(Column 4)
Pro-
grammed
AC Input
Current
Limit
[GRID MAX
CURRENT/
GEN MAX
CURRENT]
(See Note 4)
(Column 5)
NEC Ampac-
ity = 125% of
Column 5
(See Note 5)
(Column 6)
Conductor
Size Based
on NEC
Ampacity at
Column 6
(See Note 6)
(Column 7)
External
Breaker
Size
Based
on NEC
Ampacity at
Column 6
(See Note 7)
(Column 8)
EVO-2212
(2200VA, 18A)
18 A 15A 33A
30A
(Default)
37.5A AWG #8 40A
EVO-2224
(2200VA, 18A)
18A 19A 37A
EVO-3012
(3000VA, 25A)
25A 20A 45A
EVO-4024
(4000VA, 33A)
33A 29A 62A
TABLE 1.1(b) SIZING OF GRID AND GENERATOR INPUT WIRING AND BREAKERS FOR FULL RATED
AC INPUT CURRENTS FOR EVO-2212, EVO-2224, EVO-3012, EVO-4024
Model No. and
Rated Output
Power in In-
verter Mode
(Column 1)
Rated
AC Pass
Through
Current
(See Note
1)
(Column 2)
Rated AC
Charging
Current
(See Note
2)
(Column 3)
Total Rated
AC Input
Current
(Columns
2 +3)
(See Note 3)
(Column 4)
Pro-
grammed
AC Input
Current
Limit
[GRID MAX
CURRENT/
GEN MAX
CURRENT]
(See Note 4)
(Column 5)
NEC Ampac-
ity = 125% of
Column 5
(See Note 5)
(Column 6)
Conductor
Size Based
on NEC
Ampacity at
Column 6
(See Note 6)
(Column 7)
External
Breaker
Size
Based
on NEC
Ampacity at
Column 6
(See Note 7)
(Column 8)
EVO-2212
(2200VA, 18A)
18 A 15A 33A 33A 41.25A AWG #8 45A
EVO-2224
(2200VA, 18A)
18A 19A 37A 37A 46.25A AWG #8 50A
EVO-3012
(3000VA, 25A)
25A 20A 45A 45A 56.25A AWG #6 60A
EVO-4024
(4000VA, 33A)
33A 29A 62A 62A 77.5A
AWG #4 or
2X AWG #6
80A
