6 | SAMLEX AMERICA INC.
Table 1.2 AC OUTPUT WIRING AND BREAKERS
Item
(Column 1)
Rated AC Output
Current in In-
verter Mode
(Column 2)
NEC Ampacity =
125% of Column
2
(Column 3)
Wire Size based on NEC
Ampacity at Column 3
and 75°C Copper Conduc-
tor in Conduit
(Column 4)
Breaker Size
(Based on NEC Am-
pacity at Column 3)
(Column 5)
EVO-2212 18.33A 22.91 AWG #10 25A
EVO-2224 18.33A 22.91 AWG #10 25A
EVO-3012 25A 31.25 AWG #8 35A
EVO-4024 33.33A 41.66 AWG #8 45A
TABLE 1.3(a) BATTERY CABLES IN FREE AIR AND EXTERNAL BATTERY SIDE FUSES
Item Copper, 90°C Fuse
Up to 5 ft. Up to 10 ft.
EVO-2212 AWG #3/0 AWG #4/0 350A
EVO-2224 AWG #2 AWG #2 175A
EVO-3012 2 X AWG #3/0 (MCM 300) 2 X AWG #3/0 (MCM 300) 500A
EVO-4024 AWG #3/0 AWG #4/0 350A
External Charger AWG #6 AWG #2 70A
TABLE 1.3 (B) BATTERY CABLES IN RACEWAY AND EXTERNAL BATTERY SIDE FUSES
Item Copper, 90°C Fuse
Up to 5 ft. Up to 10 ft.
EVO-2212 2 X AWG #4/0 (MCM 350) 2 X AWG #4/0 (MCM 350) 350A
EVO-2224 AWG #1/0 AWG #1/0 175A
EVO-3012 Not recommended Not recommended 500A
EVO-4024 2 X AWG #4/0 (MCM 350) 2 X AWG #4/0 (MCM 350) 300A
External Charger AWG #6 AWG #2 70A
TABLE 1.4 TIGHTENING TORQUES
Battery Input
Connectors
External Charger Input
Connectors
AC Input and Output
Connectors
70 kgf.cm
(5.0 lbf.ft)
35 kgf.cm
(2.5 lbf.ft)
7 to 12 kgf.cm
(0.5 to 0.9 lbf.ft)
SECTION 1 | Safety Instructions & General Information
