84 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 85
TABLE 6.3 PROGRAMMABLE AND DEFAULT PARAMETERS - GROUP "INPUT SETTING"
Group
Parameter
name
Programming Range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
INPUT
SETTING
DEFAULT FREQ
0 = 60Hz
1 = 50Hz
0 = 60Hz
GRID MAX
CURRENT
5 – 40A 5 – 70A 5 – 40A 5 – 70A 30A
GEN MAX
CURRENT
5 – 40A 5 – 70A 5 – 40A 5 – 70A 30A
HIGH CUT OFF 50 – 70Hz 65Hz
HIGH RESET 50 – 70Hz 64Hz
LOW CUT OFF 40 – 60Hz 55Hz
LOW RESET 40 – 60Hz 56Hz
TABLE 6.4 PROGRAMMABLE AND DEFAULT PARAMETERS - GROUP "INPUT LOW LIMIT"
Group Parameter name
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
INPUT -
LOW LIMIT
RESET VOLTAGE 60.0 – 100.0V 95.0V
CUT OFF POINT 1 60.0 – 100.0V 90.0V
DETECT TIME 1 0 – 2000 cycle 300 cycle
CUT OFF POINT 2 60.0 – 100.0V 85.0V
DETECT TIME 2 0 – 2000 cycle 60 cycle
CUT OFF POINT 3 60.0 – 100.0V 80.0V
DETECT TIME 3 0 – 2000 cycle 1 cycle
TABLE 6.5 PROGRAMMABLE AND DEFAULT PARAMETERS - GROUP "INPUT HIGH LIMIT"
Group Parameter name
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
INPUT -
HIGH LIMIT
RESET VOLTAGE 100.0 – 150.0V 135.0V
CUT OFF POINT 1 100.0 – 150.0V 140.0V
DETECT TIME 1 0 – 2000 cycle 300 cycle
CUT OFF POINT 2 100.0 – 150.0V 145.0V
DETECT TIME 2 0 – 2000 cycle 60 cycle
CUT OFF POINT 3 100.0 – 150.0V 150.0V
DETECT TIME 3 0 – 2000 cycle 1 cycle
SECTION 6 | Operation, Protections and Troubleshooting
