84 | SAMLEX AMERICA INC.
TABLE 6.2 PROGRAMMABLE AND DEFAULT PARAMETERS: GROUP CHARGING CURVE
Parameter
Programming Range
(Programming requires optional Re-
mote Control Model EVO-RC)
Default
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
“BULK CURRENT”
(Bulk Charge Current “Io”)
0-100A 0-130A 0-70A 0-110A 40A
“ABSORP VOLTAGE”
(Absorption Voltage)
13.5V - 16.0V 27.0V - 32.0V 14.4V 28.8V
“EQUALIZE VOLTAGE”
(Equalization Voltage)
14.0V - 16.0V 28.0V - 32.0V 14.4V 28.8V
“FLOATING VOLTAGE"
(Float Voltage)
13.0V - 15.0V 26.0V - 30.0V 13.5V 27.0V
“COMPENSATE”
(Temperature Compensation)
-3mV to -5mV /°C/Cell -4mV /°C/Cell
“LOW VOLT ALARM”
(Battery Low Voltage Alarm)
9.5V - 12.5V 19.0V - 25.0V 11.0V 22.0V
“BATT LOW VOLTAGE”
(Battery Low Voltage Shut
Down)
9.1V - 12.0V 18.1V - 24.0V 10.5V 21.0V
“LV DETECT TIME”
(Low Voltage Detect Time)
0-600 sec 10 sec
“LV CUT OFF TIME”
(Low Voltage Cut Off Time)
0-7200 sec 1200 sec
“RESET VOLTAGE”
(Battery Low Voltage Reset)
12.0V - 17.0V 24.0V - 35.0V 14.0V 28.0V
“BATT OVER VOLT”
(Battery Over Voltage Shut
Down)
14.0V - 17.0V 28.0V - 35.0V 16.0V 32.0V
“CHARGE MODE”
( 3 or 4 Stage Charging)
Normal (3-Stage) / Equalization (4-Stage) Normal (3-Stage)
"ONLINE MODE" or
"OFFLINE MODE"
0 = Off 1 = On 0 = Off
"ONLINE OPTIONS"
(For On-Line and Off Line
Modes)
0 = Option 1
1 = Option 2
0 = Option 1
"FLOATING EXIT" 10.00V to 13.00V 20.00V to 26.00V 12.00V 24.00V
"GS DETECT TIME" 0 - 600 sec 10 sec
"GEN ON TIME" 0 - 240 min 60 min
"GEN OFF TIME" 0 - 240 min 60 min
SECTION 6 | Operation, Protections and Troubleshooting
