Sampo PME42MAW User Manual

Dimensions & Weight
Additional Information
Specifications
Operating
0
Temperature 0~40 C
Relative Humidity 20~85%
Pressure 500~380 mm/hg
Non-Operating
0
Temperature -20~60 C
Relative Humidity 10~85%
Pressure 500~380 mm/hg
Acoustics
(IHF A-weight 1 meter) 32dB Max.
Sound
Residual hum(at volume Max.) 100 W Max. u
Practical Max. Audio Output (at 10% THD Max.)
Front Speaker 15W+15W Max./4 ohm
Subwoofer 15W+15W Max./4 ohm
Sound Distortion (at 250mw 1KHz) 1% Max.
Audio Output (input at 1.4Vp-p) >=1.0Vp-p
Reliability Requirement
0
The MTBF is 30,000 hrs.(back light) under operation 25 5 C (Half luminosity, motion
picture)
+
Emission Requirement
The unit shall meet the EMI limits in all screen modes as qualified by CB/CE/UL/FCC/
VCCI/ CCC/BSMI/Gost-R/S-Mark/Spring Mark and KC.
23
Width 1012mm
Height 653.7mm
Depth 160.5mm
Net Weight 55.12lbs/25Kgs
Gross Weight 68.34lbs/31Kgs

Sampo PME42MAW Specifications

General

Brand	Sampo
Model	PME42MAW
Category	Monitor
Language	English
