Samson 2469 - Page 13

EB 3132-2 EN 13
Dimensions in mm and weights
L3
L3
L
L2
L
A
SW
SW
SW
L1
L
59
(85)
245 (295)
dR
G½
(G¾)
G½
(G¾)
185 (220)
185 (220)
Ø12 (Ø19)
Ø9.5 (Ø16)
Fig. 6 · Dimensional drawings
Connection nuts
with threaded ends
Connection nuts
with flanges
Flanged body
DN 32, 40 and 50
Connection nuts
with welding ends
Values in parentheses
for DN 32 to 50
Version with
thermowell
Bulb sensor with
screw gland
