Page #40 background imageLoading...
Page #40 background image
5-10 EB 8015 EN
Installation
b) Aligning the travel indicator
scale
After mounting the actuator, the travel indi-
cator scale must be aligned. To do so, align
'0' on the travel indicator scale with the tip
of the stem connector clamp (see Fig.5-3).
1. Move the valve to the closed position.
2. Loosen the screws on the travel indicator
scale.
3. Align the travel indicator scale.
4. Fix the travel indicator scale into place
by tightening the screws.
5.3.3 Installing the valve into
the pipeline
Premature wear and leakage due to insuf-
cient support or suspension.
Î Support or suspend the valve sufciently
at suitable points.
a) Version with anges
1. Close the shut-off valves in the pipeline
at the inlet and outlet of the plant section
while the valve is being installed.
2. Prepare the relevant section of the pipe-
line for installing the valve.
3. Remove the protective caps from the
valve ports before installing the valve.
4. Lift the valve using suitable lifting equip-
ment to the site of installation (see the
'Lifting the valve' section). Observe the
ow direction through the valve. The ar-
row on the valve indicates the direction
of ow.
5. Make sure that the correct ange gaskets
are used.
6. Bolt the pipe to the valve free of stress.
7. Attach a support or suspension on the
valve, if necessary.
b) Version with welding ends
1. Proceed as described above under ‘Ver-
sion with anges’, steps 1 to 4.
2. Completely retract the actuator stem to
protect the plug from sparks during weld-
ing.
3. Weld the valve free of stress into the
pipeline.
4. Attach a support or suspension on the
valve, if necessary.
5.4 Testing the installed valve
Risk of bursting due to incorrect opening of
pressurized equipment or components.
Valves and pipelines are pressure equipment
that may burst when handled incorrectly.
Flying projectile fragments or the release of
process medium under pressure can cause
serious injury or even death.
Before working on the control valve:
Î Depressurize all plant sections affected
and the valve (including the actuator).
Release any stored energy.
NOTICE
!
DANGER
!
