Installation
5.3.1 Mounting the external
anti-rotation xture
Before mounting the actuator, the external
anti-rotation xture must be mounted onto
the plug stem in some cases. The valve must
be closed beforehand.
For SAMSON Type3271 and Type3277
Actuators with Type3273 Hand-operated
Actuator, observe the mounting and operat-
ing instructions of the hand-operated actua-
tor (handwheel) to mount the anti-rotation
xture uEB8312-X.
Standard version for valve sizes DN200/
NPS8 and larger
See Fig.5-1 and Fig.5-2
1. Insert ball bearings (310) into the recess-
es in the bonnet.
2. Place the yoke (3) on the bonnet in such
a way that the ball bearings t into the
recesses of the yoke.
3. Fasten the yoke (3) using the castellated
nut (92).
4. Fasten the hanger (83) and warning la-
bel (255), if applicable, to the yoke us-
ing the screws (82).
5. Position the travel indicator scale (84) on
the hanger (83) with the screws (85) ac-
cording to Table5-3.
6. Use a soft-faced hammer or lever press
to press the slider disks (309) with their
beveled part rst (without using any lu-
bricant) into the recesses of the clamps
(301) as far as they will go. Remove any
excess material.
7. Apply a thin lm of lubricant (114) to the
screws (303).
Impaired functioning due to incorrectly ap-
plied lubricant.
Î Do not apply any lubricant to the stem
(9), plug stem or the threads of the
clamps (301).
8. Position the clamps (301) and stem (9)
on the plug stem according to Table5-3
and tighten screws (303) and washers
(304) by hand.
9. Mount the actuator. See section5.3.2.
10. Thread the stem (9) upwards until the
head of the stem rests on the extended
actuator stem.
11. Retract the actuator stem to relieve the
stem (9).
12. Tighten the screws (303) gradually in a
crisscross pattern. Observe the tightening
torques specied in Table5-2.
Table5-2: Tightening torques
Screw size Tightening torque
[Nm]
M12 50
M16 121
13. Check and ensure the following points:
− There is a nominal gap between 0.5
and 1mm between the slider disks
and their seating surface on the yoke
on each side (see detailed view Y in
Fig.5-2).
3
83
82
82
310310
92
84
85
255
Legend
3 Yoke
82 Screws
83 Hanger
84 Travel indicator scale
85 Screws
92 Castellated nut
255 Warning label
310 Ball bearing
Plug stem
Fig.5-1: Overview of yoke assembly with travel indicator scale
