EB 8015 EN 4-3
Shipment and on-site transport
Fig.4-1: Lifting points on the control valve: up to DN150 with anges (left) and with welding ends
(middle) · DN150 and larger with additional lifting eyelet on the actuator (right)
− Protect the piping and any mounted
valve accessories against damage.
− Protect the control valve against moisture
and dirt.
− The permissible transportation tempera-
ture of standard control valves is –20 to
+65°C.
Contact our after-sales service for the trans-
portation temperatures of other valve ver-
sions.
4.3.2 Lifting the valve
To install a large valve into the pipeline, use
lifting equipment (e.g. crane or forklift) to lift
it.
Note
