Markings on the device
The valve nameplate (80) in valve sizes
DN15 to 150 is afxed to the ange
(Fig.2-2). The valve nameplate in valve sizes
DN200 and larger is located on the yoke
(Fig.2-3).
80
80
Fig.2-2: Nameplate
on the
ange
Fig.2-3: Nameplate
on the yoke
2.2 Actuator nameplate
See associated actuator documentation.
2.3 Material numbers
The seat and plug of the valves have an item
number written on them. You can contact us
stating this item number to nd out which
material is used. Additionally, a seat code is
used to identify the trim material. This seat
code is specied on the nameplate.
2.4 Label when an adjustable
packing is installed
An instructional label is afxed to the valve
when an adjustable packing is installed (see
Fig.2-4).
Fig.2-4: Label when an adjustable packing is
installed
