EB 8310-6 EN 5-3
Mounting and assembly
2
84
9
10
8
A8
A7
A26/27
a
x
2 Bonnet/ange
8 Threaded bushing
9 Stem connector nut
10 Lock nut
84 Travel indicator
scale
A7 Actuator stem
A8 Ring nut
A26/27 Stem connector
clamps
Dim. A Refer to Table 5-1
Dim. x See 'Reversal of the
direction of action'
in the 'Service and
conversion work'
section.
Fig.5-1: Type3271 Pneumatic Actuator mounted on globe valve
